- Description
-
Details
For precision mechanical work.
Suitable for the take-up of bits with 4 mm halfmoon drive and bits with 4 mm HIOS drive.
Electrical surface resistance of < 10^9 Ohm for secure protection against electrostatic charge.
Manufactured in accordance with DIN EN 61340-5-1.
Compact handle/interchangeable blade system for fast blade change.
Kaftform Micro handle with twist cap and free-turning zone for rapid twisting, making any time-consuming re-positioning of the fingers unnecessary.
Torque value can be changed within the available torque range of 0.02-0.06Nm by removing the cap at the top of the handle and adjusting the setting screw with a 1.5mm hexagon socket screwdriver.
Torque value is pre-set to 0.035Nm, an audible and noticeable signal is heard when the pre-set value is exceeded.
Precision zone directly above the blade for the right angle for adjustment work.
Bits for manual as well as power tool operations.
Rapid fixing of the bit: just push the bit into the insert for automatic locking and a secure fit.
To change the bit, simply push the sleeve forward and remove.
Free-turning sleeve for simple guidance of the tool during the screwdriving process.
Set contains:
1013 Kraftform Micro ESD: 1 x 97.
851/9 C: 1 x PH 00x44 (optimised for Asian PH screws). 1 x PH 0x44 (size 0 modificated according to JCIS 0 - Japanese Camera Industrial Standard). 1 x PH 1x44 (optimised for Asian PH screws).
867/9 C TORX®: 1 x TX 1x44, 1 x TX 2x44, 1 x TX 3x44, 1 x TX 4x44, 1 x TX 5x44, 1 x TX 6x44.
867/9 C TORX PLUS®: 1 x 1 IPx44, 1 x 2 IPx44, 1 x 3 IPx44, 1 x 4 IPx44.
840/9 C: 1 x 1.5x44, 1 x 2.0x44.
800/9 C: 1 x 0.23x1.5x44, 1 x 0.40x2.0x44, 1 x 0.50x3.0x44.
867/9 IPR TORX® PLUS: 1 x 1 IPRx44.
