- Description
-
Details
Aluminium cylinder head with cast iron cylinder gives added resistance to wear.
Suitable for on-site applications or anywhere that requires 110V.
Pump head directly coupled to heavy-duty induction motor for reliable and smooth operation.
Precision welded receiver tank manufactured to meet Pressure Vessel Directive 2009/105/EC.
Fitted with fully automatic pressure cut-out switch and twin gauges displaying tank and working pressures.WARNING: The compressor is supplied without oil in it. The oil is supplied in a separate container.
For oil recommendations and further information please click here to view user instructions.- Features
Features
Motor Output:
2hp Supply: 110V Phase: 1ph Minimum Rated Supply: 16A Air Displacement cfm(ltr/min): 6.3(178) Maximum Free Air Delivery cfm(ltr/min): 4.6(130) Maximum Pressure: 116psi(8bar) Receiver Capacity: 24ltr Outlet: Quick Release Coupling Size (W x D x H): 600 x 290 x 585mm Weight: 26.5kg
