- Description
-
Details
Lifts 3000kg at 1200mm jib extension.
Heavy-duty castors.
Perfect for heavy commercial, industrial and workshop use.
Extendable heavy-duty legs for improved stability, particularly when operating at maximum jib extensions.
Pump access from side and dead man's lowering mechanism for safe handling of heavy loads.
Delivered in knock-down form for reduced freight cost.
Some self assembly required.- Features
Features
Height Jib Down:
1610mm Height Legs Folded: n/a Height of Frame: 195mm Length Legs Extended: n/a Length of Jib Position 1: 1200mm Length of Jib Position 2: 1400mm Length of Jib Position 3: 1610mm Length of Jib Position 4: 1820mm Length of Jib Position 5: n/a Length: 1940mm* Lifting Capacity in Position 1: 3000kg Lifting Capacity in Position 2: 2000kg Lifting Capacity in Position 3: 1500kg Lifting Capacity in Position 4: 1000kg Lifting Capacity in Position 5: n/a Max. Lift Ht at Jib Position 1: 1880mm Max. Lift Ht at Jib Position 2: 1970mm Max. Lift Ht at Jib Position 3: 2010mm Max. Lift Ht at Jib Position 4: 2220mm Max. Lift Ht at Jib Position 5: n/a Note: *Legs Extended Rear Width: 780mm Width Front Frame: 855mm* Width Inside Front Frame: 700mm*
