2-SPEED DRY DIAMOND DRILL
- Metal gearbox for long service life.
- 2-speed gear box.
- Friction clutch in both gears, additional electronic safety clutch.
- Electronics: Softstart via accelerator-switch for precision-drilling and motor overload protection.
- High-spindle torque.
- Excellent soft percussion mechanism for maximum drilling performance.
- Long AVS handle reduces harmful vibrations and offers better control.
- New FIXTEC system for easy change of core bits.
- Power input: 1,500W. No-load speed: 0-1,500/0-3,000rpm.
- Drilling speed (full-load): 0-890/0-1,770rpm.
- Impacts: 24,000/48,000 Ipm
- Spindle diameter and thread: M18
- Chuck capacity: 3-16mm. Gear neck diameter: 57mm.
- Weight: 4.2 kg
- With this Milwaukee DD2160XE we supply 4mtr Long Cable, Anti-Vibration System Handle, 3-jaw Chuck & Key and Carrying Case. Image shows diamond core bit (not supplied).
- Features
Features
Chuck capacity (mm) 162 Full load speed [rpm] 0 - 890 / 0 - 1770 Max. drilling masonry (mm) 162 Max. static stalling torque (Nm) 50 No load hammer stroke (rpm) 24,000 / 48,000 No load speed (rpm) 0 - 1500 / 0 - 3000 Power input (W) 1500 Supplied in Kitbox Vibration drilling (m/s²) 13 Vibration drilling uncertainty [m|s²] 3.6 Weight (kg) 4.2
