- Description
-
Details
- Optimum force transmission due to four-way expansion
- This allows for high holding values in solid and hollow building materials.
- Simple to assemble:
- The edge of the plug prevents it from falling deeper into the drill hole
- No expansion pressure on the plug neck
- This means that tiles or plaster are not damaged.
Advantages
- The 4-way expansion provides the optimum force distribution in the material, and offers high load-bearing capacities in solid and hollow building materials
- The expansion-free plug neck prevents the creation of expansion forces on the material surface whilst screwing in the screw.
- This helps to prevent damage to tiles and plaster
- The pronounced rim prevents the plug from slipping into the drill hole, thus allowing for a simple installation
Functionality
- The SX with rim is suitable for pre-positioned installation
- When turning in the screw, the SX expands in four directions, thus providing a secure anchoring in the building material
- The required screw length is given by: Plug length + fixture thickness + 1 x screw diameter
- Suitable for wood, chipboard and spacing screws fischer ASL.
Load Table
- Features
Features
Drill diameter 6 mm Min. drill hole depth 60 mm Anchor length 50 mm Wood and chipboard screws 4.0 - 5.0 mm Amount 100 pcs. Packaging Folding box GTIN (EAN-Code) 4006209248270 Applications Shelves Mirror cabinets TV consoles Folding shutters Bath and toilet installations Building materials Concrete Vertically perforated brick Hollow blocks made from lightweight concrete Cavity floor slabs made from bricks and concrete Perforated sand-lime brick Solid sand-lime brick Natural stone with dense structure Aerated concrete Solid panel made from gypsum Solid brick made from lightweight concrete Solid brick
