- Description
-
Details
- The Fischer window frame fixing F-S is a special plug for the stress-free stand-off installation of window and door frames
- It consists of a plug made from high-qualify nylon and a countersunk head screw with a cross-slot recess made from zinc-plated steel
- The F-S is set in a time-saving push-through installation
- When the screw is tightened, the fibre-glass reinforced plastic cone is pulled into the plug sleeve and expands against the wall of the drill hole
- This ensures a fixation that is free from tensile force and pressure, thus guaranteeing a secure hold in all building materials
Top Features
- Stress-free, durable fixing of the frame
- Continuous thread prevents the frame from being pulled
- Use for all solid and hollow building materials lowers complexity
- Compression and tensile-resistant anchoring of metal and plastic profiles
- Cover cap covers screw head
Advantages
- The operating principle of the plug prevents the frame from being pulled against the substrate, and ensures a stress-free and long-lasting fixing of the frame
- The special plug geometry anchors the metal and plastic profiles against compressive and tensile loads, and allows for a secure hold of the window frame
- The cover cap (available separately) can be used to discreetly cover the screw head
Functioning
- The F-S is suitable for push-through installation
- By tightening the screw, the glass-fibre-reinforced plastic cone is drawn into the sleeve, whereby it is expanded and wedged inside the drill hole
- The window frames are thus fixed in a stress-free manner.
- The maximum installation torque is 3 Nm
Load Table For Downloading
https://content.fischer.de/cbfiles/fischer/lastentabelle/lt_01_f-s-n_f_%23sen_%23aip_%23v2.pdf
- Features
Features
Drill hole diameter d0 10 [mm] Effect. anchorage depth hef 50 [mm] Anchor length l 100 [mm] Max. fixture thickness t fix 40 [mm] Min. drill hole depth for through fixings h2 115 [mm] Max. installation torque Tinst 6 [Nm] Amount 50 Unit(s) GTIN (EAN Code) 4006209886267 Applications Window frames Door frames Building materials Concrete Vertically perforated brick Hollow blocks made from lightweight concrete Perforated sand-lime brick Solid sand-lime brick Aerated concrete Solid brick made from lightweight concrete Solid brick
