- Description
-
Details
Top Features
- The specially hardened red tip provides a faster and more secure installation
- The stainless steel concrete screw guarantees a high level of corrosion resistance especially for wet rooms and external applications
- The approved adjustment for the concrete screws allows the screw to be unscrewed twice to align the attached part, and then to tighten the screw again.
Advantages
- The specially hardened red tip provides a faster and more secure installation
- The stainless steel concrete screw guarantees a high level of corrosion resistance especially for wet rooms and external applications
- The special saw tooth geometry enables fast cutting into the concrete
- Drill holes do not need to be cleaned during vertical installation (ceiling and floor)
- For floor fixings the hole must be drilled 3x drill hole diameter deeper
- The ETA approval covers applications in cracked concrete and seismic power categories C1 and C2
- The approved adjustment for the concrete screws allows the screw to be unscrewed twice to place maximum 10 mm packing below the base plate head or to align the attached part, and then to tighten the screw again
- The three embedment depths, allow for using the UltraCut FBS II R in many different applications and enable a high flexibility
- The short UltraCut FBS II R, with a reduced embedment in depth, allows for a short drill hole depth, fast installation and less reinforcement hits
Functionality
- The UltraCut FBS II R is recommended for the push-through installation
- Drill holes do not need to be cleaned during vertical installation (ceiling and floor)
- For floor fixings the hole must be drilled 3x drill hole diameter deeper
- We recommend using a tangential impact screwdriver with a suitable impact screwdriver socket or an internal TX drive
- The screw is installed correctly when the screw head sits flush on the fixture and cannot be screwed in deeper (visual setting control)
ETA Certification Document
DOP - Declaration of Performance
- Features
Features
ETA-approval Drill diameter 8 mm Min. drill hole depth for through fixings 90 mm Screw 10.0 x 80 mm Screw-in depth with fixture thickness 50 / 30 mm Screw-in depth with fixture thickness 65 / 15 mm Drive TX40 Packaging Folding box Amount 50 pcs. GTIN (EAN-Code) 4048962308327 Applications Guard rails Consoles/Base plates Metal profiles Steel constructions Façades Protection barriers Building materials Approved for: Concrete C20/25 to C50/60, cracked and non-cracked Also suitable for: Concrete C12/15 Solid building materials Masonry with a dense structure Approvals ETA-17/0740 DoP No. 0134
