Fischer 542797 DuoTec 12 S PH Panhead Screw Box x 10

More Views

Fischer 542797 DuoTec 12 S PH Panhead Screw Box x 10
Ex. VAT £9.44 Inc. VAT £11.33

Usually ships within 2 working days

The installation-friendly solution for high loads in panel building materials

Description

Details

  • The nylon toggle fischer DuoTec for high tensile and transverse loads through 2 components
  • Easy installation with small drill hole diameters of 10 mm and short toggle element, even in narrow and insulated cavities
  • Easy pre-installation; the plug does not fall into the drill hole, even without a screw
  • No cutting, and thus no weakening of the gypsum plasterboard
  • The toggle element automatically folds behind the panel and gives it its strength
  • As a result of the flexible stainless steel screw seat, the gravity toggle can be used with wood and chipboard screws or metric hooks and threaded rods with lock nuts
  • If it hits something in the drill hole in solid building materials, it functions like an Expansion plug

Top Features

  • Combination of two material components for more performance
  • Flush sleeve strengthens the drill hole and allows considerably higher transverse loads
  • Curved handle allows obstacles to be identified before installation
  • With corresponding panhead screw

Features

Features

Applications
Kitchen hanging cabinets
Living room cabinets
Shelves
Wardrobes
Handrails
Pictures
Mirrors
Lamps
Heavy hanging baskets
Building materials
Suitable for:
Gypsum plasterboard
Gypsum fibreboard
Wooden panels, such as OSB boards, chipboard, MDF sheets
Steel plates
Plastic boards
Hollow blocks made from concrete
Also functioning in:
Solid materials, such as concrete and wood
Drill diameter d0 12 [mm]
Min. panel thickness dp 9.5 [mm]
Max. panel thickness dp 55 [mm]
Min. cavity depth a 50 [mm]
Screw diameter ds M6 [mm]
Screw length ls 70 [mm]
Anchor length l 60 [mm]
Packaging Folding box
Amount 10 [pcs.]
GTIN (EAN-Code) 4048962299847
