- Description
-
Details
- Two component materials for top load values and intelligent functioning depending on the substrate
- Great feedback (feel-good factor) of the plug
- You can feel exactly when the plug is installed perfectly
- The short plug length ensures fast fixing without deep drilling
- The narrow plug rim prevents slipping into the drill hole
- The serrated anti-rotation feature prevents rotation in the drill hole during installation
- The greater anchorage depth of the DUOPOWER 6 x 50, 8 x 65 and 10 x 80 means that the plug is especially suited to fixings in hollow building materials, aerated concrete and to bridge plaster
For the following building materials
- Concrete ▪ Solid brick ▪ Solid sand-lime brick ▪ Aerated concrete ▪ Vertically perforated brick ▪ Perforated sand-lime brick ▪ Plasterboard Gypsum plasterboard and gypsum fibreboards ▪ Hollow blocks made from lightweight concrete ▪ Cavity floor slabs made from bricks and concrete or similar ▪ ▪ Natural stone ▪ Chipboard ▪ Solid panel made from gypsum Solid brick made from lightweight concrete
- Features
Features
Drill hole diameter d 0 6 [Mm] Min. Borehole depth h 1 65 [Mm] Min. Plate thickness d p 12.5 [Mm] length of anchor l 50 [Mm] Min. Screw-in depth l E, min 55 [Mm] Chipboard / wood screws d s / d s xl s 4,5 x 60 [Mm] drive PZ2 Max. Thickness of the attachment t fix 15 [Mm] amount 50 Units) GTIN (EAN Code) 4048962262124
