- Description
-
Details
Top Features
- Cost-effective fixing due to low anchorage depth
- Plug expands in solid building materials
- The plug anchors itself in the cavity in perforated building materials
- Screw with cross-slot recess
Advantages
- The special functioning allows for use in solid and hollow building materials with an anchorage depth of just 30 mm, thus ensuring an economic fixing
Functionality
- The SXR is suitable for push-through installation
- The SXR expands in solid building materials
- In perforated building materials, the loads are transferred in the block fillet area
- With vertically perforated bricks, only use rotary drilling (no impact drilling)
- Recommended for the fixing of wood constructions
Load Table
- Features
Features
Drill diameter 6 mm Min. drill hole depth for through fixings 70 mm Anchor length 60 mm Max. fixture thickness 30 mm Drive PZ2 Packaging Folding box Amount 50 pcs. GTIN (EAN-Code) 4048962055498 Applications Timber sub-structures Blinds / folding shutters Handrails Wardrobes Shelves Lighting Motion detectors Wall covering Metal brackets Metal supports Cable ducts Cable trays Building materials Suitable for: Vertically perforated brick Aerated concrete Hollow blocks made from lightweight concrete Perforated sand-lime brick Thermal insulation blocks Solid block made from lightweight and normal weight concrete Solid brick Solid sand-lime brick Concrete ≥ C12/15 Natural stone with dense structure Solid panel made from gypsum
