- Description
-
Details
For use with either gas or gasless MIG wire of up to 15kg spool sizes.
Features:
• Euro torch connector
• Spot welding timer for precise spot welds
• Six stage power setting
• Variable wire speed control
• Thermal overload protection
• Dinse fit earth clamp
• 0.6/0.8mm wire feed roller
Supplied with wheel kit and reinforced gas bottle support.
Gas bottle, regulator, MIG wire, etc are all available separately (examples listed under Related Products).
Note: For a successful weld joint, the molten metal must be protected from contaminating gases found in the air. This is either achieved by supplying the torch with gas from a bottle or setting the machine up for no-gas and using a flux cored filler wire. The shield is produced as the flux in the wire melts. To connect a gas bottle to the welder, you may need a suitable regulator such as Draper Stock No.44352, or similar.- Features
Features
Phase 230V/400V Input current 32A Output amperage range 80 - 250A Absorbed current 13.5KW Duty cycle 20% @ 250A , 100% @ 80A Welding wire size 0.8 - 1.2mm No load voltage 37V Dimensions 845 x 415 x 505mm Weight 58kg
